RunnTech Single-axis Self-centring +/-10V Analog Output Joystick with On/Off Pushbutton

Part number: RT100-T-1-V1(10K)-01(5)-HD4-BT1R-M1

• RT100: RunnTech 100 series multi-axis joystick;
• T: self-centring when grip released;
• 1: single axis 2 directions movement;
• V1: input: 24Vdc, output: +/-10Vdc;
• 10K: 10K ohm precision potentiometer;
• 01(5): 1 contacts @ center position;
• HD4-BT1R: grip top with 1 momentary pushbutton;
• M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech 2 Axis Friction Position Proportional Control Joystick with 1 On/off Pushbutton

Product configuration: RT02-M-3-HV1(H)-03(666)-HD11-BT1R-M6

• RT02: RunnTech 02 series rugged joystick controller;
• M: friction hold position;
• 3: Y/X axis full direction movement;
• HV1: input: 5 Vdc, output: 0 ~ 2.5 ~ 5 Vdc;
• 03: 3 sets normally open contacts in each axis;
• 6: contacts @ -32° to -3° and +3° to +32°;
• HD11-BT1R: grip top with 1 momentary pushbutton;
• M6: mounting dimension: 76x76mm, central hole: 92mm.

RunnTech 2 Axis Proportional Joystick with Y-axis & Z-axis (Clockwise/counterclockwise)

Part number: RT600-T-2(YZ)-HV1-HD12-BT2-M11

• RT600: RunnTech RT600 Hall effect joystick controllers;
• T: self-return to center;
• 2: 2 axis (Y and Z axis) control;
• Y-axis: forward and backward control;
• Z-axis: clockwise and counterclockwise (twist knob on top of handle);
• HV1: input: 5Vdc, output: 0Vdc to 2.5Vdc (center) to 5Vdc;
• HD12-BT2: RunnTech joystick grip with 2 momentary pushbuttons;
• M11: mounting dimension: 36x36mm, centeral hole: 38mm;

RunnTech Single-axis with Special Limiter Plate Self-return 4-12-20mA Output Joystick

Part number: RT02-TS-1b-I1(10K)-02(89)-HD9-BT4④⑤G⑥⑦R-M6

• RT02: RunnTech 02 series robust joystick controller;
• TS: mechanical self-centering operation with center-lock;
• 1b: single axis with special limter plate;
• I1: input: 24Vdc, output: 4mA~12mA~20mA;
• 10K: 10K ohm precision potentiometer;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32° in each axis;
• HD9: ergonomic grip with momentry pushbuttons;
• BT4④⑤G⑥⑦R: 2 green and 2 red momentary pushbuttons;
• M6: mounting dimension: 76x76mm, central hole: 92mm.

RunnTech Single-axis Joystick Controller to Control Proportional Valve to Operate Winch

Part number: RT200-TS-V1(10K)-02(89)-HD6-M1

• RT200: RunnTech 200 series single axis joystick;
• TS: spring return to center with center-lock;
• V1: input 24Vdc, output: -10~0~+10Vdc (proportional);
• 10K: 10K ohm precision potentiometer;
• 02: 2 normally open contacts;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD6: joystick grip with zero interlock (press to release joystick);
• M1: mounting dimension: 56x56mm, central hole: 63mm;

RunnTech Single-axis Joystick Controller with 4 Steps Movement and Lift to Release Grip

Product configuration: RT300-TS-1-I-2(1)-HD5-M5

• RT300: RunnTech RT300 series joystick lever (master controller);
• TS: spring return to center and center-lock;
• 1: single axis movement;
• I: switch assembled vertical;
• 2: 4 steps movements (2 steps forward and 2 steps backward;
• (1): contacts arrangement;
• M5: mounting dimension: 85x85mm, central hole: 78mm.

RunnTech Single-axis 4 to 20mA Analog Output Joystick with Deadman & Rocker Switch

Product configuration: RT100-T-1-I1(10K)-02(89)-HD15-BT1-QTOT-M1

• RT100: RunnTech 100 series industrial joystick controller;
• T: self-return to middle position operation;
• 1: single axis movement (default: Y axis);
• I1: input: 24Vdc, output: 4mA ~ 12mA ~ 20mA;
• 10K: 10K ohm precision potentiometer (with center tapped);
• 02: 2 normally open contacts in Y axis;
• (8): contacts @ +3° to +32° (directional micro-switches);
• (9): contacts @ -3° to -32° (directional micro-switches);
• HD15: HD15 grip handle with 1 deadman trigger and rocker switch;
• M1: mounting dimension 56x56mm, central hole: 63mm;

RunnTech 2 Axis 1 Pushbutton Fingertip Joystick 0V to 5V Analog Output with Limiter Plate

Product configuration: RT600-T-2-03-HV1-HD13-BT1R-M11

• RT600: RunnTech RT600 series Hall sensor miniature joystick;
• T: self-return to center on all Y/X axises;
• 2: dual axis control;
• 03: Y & X axis 360° free movement;
• HV1: input: 5Vdc, output: 0~2.5~5Vdc;
• HD13-BT1R: HD13 grip with 1 momentary pushbutton;

RunnTech Dual-axis Self-centering Proportional Joystick with 10K Ohm Potentiometer

Product configuration: RT100-T-2-P1(10K)-02(89)-HD1-BT1R-M1

• RT100: RunnTech 100 series joystick controller;
• T: mechanical spring return to center (self-centering);
• 2: dual axis cross movement;
• P1: simple 2 directions proportional output;
• 10K: 10K ohm precision potentiometer;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD1-BT1R: grip with 1 momentary push button;
• M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech Single-axis 10K Potentiometer Joystick with Deadman Trigger & Rocker Switch

Product configuration: RT100-T-1-V4(10K)-02(89)-HD15-BT1-QTOT-M1

• RT100: RunnTech 100 series industrial joystick controller;
• T: self-centering operation;
• 1: single axis movement (default: Y axis);
• V4: input: 24Vdc, output: +5Vdc ~ 0 ~ +5Vdc;
• 10K: 10K ohm precision potentiometer;
• 02: 2 normally open contacts in Y axis;
• (8): contacts @ +3° to +32° (directional micro-switches);
• (9): contacts @ -3° to -32° (directional micro-switches);
• HD15: HD15 grip handle with 1 deadman trigger and rocker switch;
• M1: mounting dimension 56x56mm, central hole: 63mm;
