RunnTech RT100 Series Multi-axis Joystick Controller Video Demostration

RT100 industrial joystick controller, is mainly used in hydraulic proportional control or variable frequency motor control, such as Rotary table (drilling rig), Crane, Aerial work platforms, Forklift trucks, Mobile hydraulics, Shield tunneling machine, Hoist, Marine, Construction machinery, Civil engineering, Military vehicles, Cabin vehicles, Military robotics, Precision machine tools, Refuse handling trucks, Fire and off-highway vehicle,…

RunnTech Multi-axis Hoisting Equipment Master Controller with 2X5kOhm Potentiometer

Product configuration: RT300-T-3-L-P1(5K)-3(1)-HD2-M5

• RT300: RunnTech RT300 series crane joystick (master controller);
• T: mechanical self-centering movement operation;
• 3: dual axis, full direction movement;
• L:switch assembled horizonal;
• 3(1): 6 steps each axis, (1): contact arrangement;
• P1: simple 2 direction output with center tapped;
• 5K: 5K ohm precision potentiometer;
• HD2: round ball shape joystick grip;
• M5: mounting dimension: 85x85mm, central hole: 78mm.

RunnTech Single-axis +5VDC Analog Signal Outputs Joystick Controller for Winch Control

Product configuration: RT200-TS-1-V4(10K)-02(89)-HD6-M1

• RT200: RunnTech 200 single axis joystick;
• TS: mechanical spring return to netural and zero interlock;
• V4: input DC24V, output: +5V~0V~+5V;
• 10K: 10K ohm precision potentiometer;
• 02: 2 normally open contacts in Y axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD6: joystick grip with zero interlock (press to release joystick);
• M1: mounting dimension: 56x56mm, central hole: 63mm;

RunnTech Proportional Foot Accelerator Pedal with 1 Normally Opened Switch for Forklift

Product configuration: F100-T-V5(1K)-01(2)

• F100: F100 series proportional accelerator pedal;
• T: mechanical self-centering operation;
• V5: input: DC24V, output: 0~+10V;
• 1K: 1K ohm precision potentiometer;
• 01: 1 normally open contacts;
• (2): contacts @ 3° to 25°;

RunnTech Multi-axis Y & X Axis Free Movement Joystick Controller for Steel Rolling Mills

Product configuration: RT300-M-3-I-3(1)-HD39-M5

• RT300: RunnTech RT300 series hoist joystick (master controller);
• M: friction-hold/brake operation;
• 3: Y & X axis free movement;
• I: switch assembled vertical;
• 3(1): 6 steps each axis, (1): contacts arrangement;
• HD39: RunnTech joystick handle part number;
• M5: mounting dimension: 85x85mm, central hole: 78mm.

RunnTech Single-axis Industrial Analog Output Joystick Controller for Conveyor System

Product configuration: RT200-TS-P1(10K)-02(89)-HD5-M1

• RT200: RunnTech 200 series single-axis joystick;
• MS: mechanical spring return with zero interlock (pull to release);
• P1: simple 2 direction output with center tapped;
• 10K: 10K ohm precision potentiometer;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD5: joystick grip with zero interlock;
• M1: mounting dimension: 56x56mm, central hole: 63mm;

RunnTech Single-axis Spring Return 0~20mA Analogue Output Joystick for Crane Control

Product configuration: RT200-TS-I2(0-20mA)(10K)-02(89)-HD6-M1

• RT200: RunnTech 200 series single axis joystick;
• TS: mechanical spring return to zero position and zero interlock;
• I2(0-20mA): input DC24V, output: 20mA~0mA~20mA;
• 10K: 10K Ohm conductive-plastic potentiometer with solid center tap;
• 02: 2 normally open contacts in Y axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD6: joystick grip with zero interlock (press to release joystick);
• M1: mounting dimension: 56x56mm, central hole: 63mm;

RunnTech Dual-axis Joystick with Ergonomic Multifunction Handle and Deadman Trigger

Product configuration: RT01-T-2-V2(10k)-02(89)-HD10b5-BT5②③⑤⑥G④R-M4

• RT01: RunnTech 01 series industrial joystick;
• T: mechanical spring return to center;
• 3: dual axis full direction movement;
• V2: input: DC 24V, output: +10V~0~+10V;
• 10K: 10K ohm precision potentiometer;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD10b5: grip with 1 momentary trigger switch & 5 button;
• M4: mounting dimension 64x64mm, central hole: 83mm.

RunnTech 1-axis +/-10V DC Analog Output Industrial Potentiometer Joystick Controller

Product configuration: RT200-TS-V1(10K)-03(589)-HD5-M1

• RT200: RunnTech 200 series single-axis joystick;
• TS: spring-back to centre position with zero interlock;
• V1: 24VDC input, -10V – 0 – +10V analog output;
• 03(589): 2 micro-switches for position indication and 1 micro-switch for indication of neutral position;
• HD5: grip with zero interlock (pull to release);
• M1: mounting dimension: 56x56mm, central hole: 63mm;

RunnTech Dual-axis 10K Ohm Conductive-plastic Solid Center Tap Potentiometer Joystick

Product configuration: RT100-T-2-P1(10K)-02(66)-HD8-M1

• RT100: RunnTech 100 series industry joystick controller;
• T: spring return to center when release operation;
• 2: dual axis, cross direction movement operation;
• P1: simple 2 direction output with center tapped;
• 10K: 10K ohm precision potentiometer;
• 02(66): 4 normally open contacts in each axis;
• 66: contacts @ -32° to -3° or +3° to +32°;
• HD8: RunnTech joystick grip;
• M1: mounting dimension 56x56mm, central hole: 63mm.
