RunnTech 2 Axis Voltage Output Joystick Control with 10K Ohm Precision Potentiometer

Product configuration: RT100-T-3-V2(10K)-02(89)-HD1-M1

• RT100: RunnTech RT100 series joystick controller;
• T: self-resetting operation;
• 3: 2 axis, free movement;
• V2: input: DC 24V, output: +10V…0V…+10V;
• 10K: potentiometer resistor is 10K;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD1: RunnTech joystick handle model.

RunnTech Multi-axis Hall Effect DC5V Input Joystick with 2 Thumbwheel Controller

Product configuration: RT100-T-3-HV2-HD10b9-W100Lx2-HV2-M7

• RT100: RunnTech RT100 series joystick controller;
• T: self-resetting operation;
• 3: 2 axis, free movement;
• HV2: input: DC 5V, output: 0.5V…2.5V…4.5V;
• HD10b9: RunnTech handle model with 2 thumb wheels;
• W100L: thumb wheel controller model;
• M7: mounting dimension.

RunnTech Multifunction Control Handle (Tiller Head): H100-G-L-T

• H100: RunnTech H100 series tiller head;
• G: turtle speed button;
• L: horn button;
• T: speed controller (throttle);

RunnTech 2 Axis Cross Limiting Plate Spring Return 10K Potentiometer Joystick

Product configuration: RT100-T-2-P1(10K)-HD8-M1

• RT100: RunnTech RT100 series joystick controller;
• T: self-resetting spring return operation;
• 2: 2 axis, cross direction movement;
• P1: simple dual directions output;
• 10K: 10K potentiometer resistor;
• HD8: RunnTech joystick grip type;
• M1: mounting dimension.

RunnTech DC 24Vdc Multi-axis Industrial Joystick Potentiometer & Momentary Pushbutton

Product configuration: RT100-T-3-02(7)-HD4-BT1-M1

• RT100: RunnTech RT100 series joystick controller;
• T: spring return;
• 3: 2 axis, free movement;
• 02: 2 micro switch in each axis, total 4 micro switches;
• 7: switch closed position;
• HD4: RunnTech joystick grip type;
• BT1: 1 self-resetting button;
• M1: mounting dimension.

RunnTech RT300 Series 2 Axes Joystick Spring Return to Center for Winche & Crane

Product configuration: RT300-T-2-L-Y4(1)-X3(1)-HD39-M5

• RT300: RunnTech RT300 series crane joystick (master controller);
• T: Self-resetting operation;
• 2: 2 axis, cross direction;
• L: switch assembled horizontal;
• Y4(1): Y axis 4 steps each direction, (1): closed position;
• X3(1): X axis 3 steps each direction, (1): closed position;
• HD39: RunnTech joystick handle type;
• M5: mounting dimension

RunnTech Y Axes Friction Hold at Any Point 1K Ohm Potentiometer Joystick Controller

Product configuration: RT100-M-1-P2(1K)-01(05)-HD2-M1

• M: friction position;
• 1: single axis (y axis);
• P2: simple single direction;
• 1K: potentiometer resistor is 1K Ohm;;
• 01: 1 direction switch;
• 05: closed position;
• HD2: round ball shape joystick grip;
• M1: mounting dimension;

RunnTech Spring Return to Middle Position Hall Sensor Joy Stick for Mining Machinery

Product configuration: RT100-T-2-HV1(H)-02(89)-HD10b4-BT4(②③)R(④⑤)G-M7

• T: spring return to center;
• 2: 2 axis, cross direction.
• HV1: 0…2.5…5V output.
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD10b4: HD10 handle with deadman button;
• BT4(②③)R(④⑤)G: 4 self-resetting push buttons;
• M7: mounting dimension 85x85mm, central hole: 80x80mm.

Industrial joystick is mainly use for what?

In recent years, industrial joysticks has been widely used in many industrial and manufacturing industry, such as; cranes, assembly lines, forestry equipment, mining trucks and excavators. In fact, this can cope with high demand lever in nearly all modern hydraulic control system actually replaces the traditional mechanical lever. Since the industrial joystick is used frequently…

RunnTech releases W200 single axis fingertip joystick for material handling equipment

After RunnTech technical team’s efforts, we are proud to announce the successful development of W200 series single axis fingertip joystick controller for remote control chest packs and the control of construction, agricultural or material handling equipment (similar as Penny & Giles | Curtiss-Wright JC100 series.

Need samples for evaluation? Just send your inquiry to info@runntech.com
