RunnTech 2 Axis Friction Brake and Center-lock Joystick Controller for Electro-hydraulic Control

Product configuration: RT02-MS-3-P1(25%-50%-75%)(10K)-02(89)-HD50-M6

• RT02: RunnTech 02 series joystick controller;
• MS: friction brake with center-lock operation;
• 3: dual axis omni-directional control;
• P1(25%-50%-75%): 25%…75%Vdc output (if input 24V, output will be 6…12…18Vdc);;
• 10K: 10K ohm center tapped potentiometer;
• 02(89): 2 directional switches in each axis;
• HD50: grip with mechanical lock-in at 0 position (lift to release the joystick);
• M6: mounting dimension: 76x76mm, central hole: 92mm.

RunnTech 2 Axis Industrial Joystick Controller with 4…20mA Output and Directional Switches

Product configuration: RT100-T-3-I2(10K)-03(589)-HD4-M1

• RT100: RunnTech 100 series joystick controller;
• T: mechanical spring return to handle centering;
• 1: single axis movement;
• I2: input: 24Vdc, output: 20mA…4mA…20mA (4mA is the centre current);
• 10K: 10K Ohm conductive-plastic potentiometer with solid center tap;
• 03（589）: 2 directional contacts and 1 center detecting contact in each axis;
• HD4: joystick grip;
• M1: mounting dimension 56x56mm, central hole: 63mm;

RunnTech 3 Axis Hall Effect Compact Fingertip Joystick for Boat and Vessel Control System Panel

Part number: RT600-T-3-03-HV1-HD12-BT2-M11

• RT600: RunnTech RT600 Hall effect joystick controller;
• T: self-centering to center position;
• 3: 3 axis control (z-axis with a twist knob);
• 03: X/Y axis omnidirectional movement, Z axis clockwise and counterclockwise;
• HV1: input: 5Vdc, output: 0…2.5…5Vdc (proportional);
• HD12-BT2: joystick knob top with 2 momentary pushbuttons;
• M11: mounting dimension: 36x36mm, centeral hole: 38mm;

RunnTech Single-axis (Up and Down) Industrial Joystick to Control Solenoid Valve through PLC

Product configuration: RT100-T-1-P1(10K)-03(589)-HD4-M1

• RT100: RunnTech 100 series joystick controller;
• T: spring return to center operation;
• 1: single axis movement (default: up/down);
• P1(10K): 10K Ohm conductive-plastic potentiometer with solid center tap (with dead zone);
• 03(589): 2 directional contacts and 1 center detecting contact in Y axis;
• HD4: grip top without momentary pushbutton;
• M1: mounting dimension: 56x56mm, central hole: 63mm.

RunnTech 3 Axis Joystick Kalmar Servo Control 920943.0058 for Kalmar Port Reach Stacker

RunnTech RT90 series multi-functional control with 6 switches (2x illuminating, 3x pushbuttons and 1x deadman trigger) and 1x proportional thumbwheel joystick controller for Kalmar (920943.0058) container reach stacker port material handling equipment (potentiometers outside-mounted type) with standard DB25 Male analog 25-pin Connector for serial connections (RunnTech part number: RT90JAM-4U-46R4GP, Kalmar part number: Servo Control 920943.0058 or 9209430058).

RunnTech Multi-axis Joystick +/-5Vdc Analog Output for Manipulation of Submersible Vehicle

Product configuration: RT100-T-3-V3(10K)-02(89)-HD7-BT1R-M1

• RT100: RunnTech 100 series joystick controller;
• T: spring return to center (self-centering);
• 3: dual axis free movement operation;
• V3: input: 24Vdc, output: -5Vdc…0…+5Vdc;
• 10K: 10K ohm precision potentiometer;
• 02(89): 2 directional contacts in each axis;
• HD7-BT1R: grip with 1 momentary push button;
• M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech Single Axis Industrial Joystick with 0…5Vdc Analog Output to Control Track Solutions

Product configuration: RT100-T-1-V6(10K)-03(589)-HD1-BT1R-M1

• RT100: RunnTech 100 series industry joystick controller;
• T: self-centering to center;
• 1: single axis operation (Y axis default);
• V6: input: 24Vdc, output: 0…2.5…5Vdc;
• 10K: 10K ohm center tapped potentiometer;
• 03(589): 2 directional contacts and 1 center detecting contact in Y axis;
• HD1-BT1R: grip top with red momentary pushbutton;
• M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech Electrical Joystick -10V…+10V Output for Marine Crane Hydraulic Proportional Valve

Product configuration: RT100-T-2-V1(10K)-01(5)-HD1-M1

• RT100: RunnTech 100 series industry joystick controller;
• T: spring return to center operation;
• 2: dual axis, plus (+) direction movement;
• V1: input: 24VDC, output: -10Vdc…0…+10Vdc;
• 10K: 10K ohm precision potentiometer;
• 03(589): 1 center detect contact and 2 directional contacts in each axis;
• HD1: HD1 joystick grip (top without momentary pushbutton);
• M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech Stepless Joystick 4…20mA to Control Movement of Overhead Crane Bridge & Trolley

Product configuration: RT02-T-2-I1(10k)-02(89)-HD11-M6

• RT02: RunnTech 02 series robust joystick controller;
• T: spring return to center operation;
• 2: Y/X axis plus direction (+) movement;
• I1: input 24Vdc, output: 4 wire 4mA…12mA…20mA (current output);
• 10K: 10K ohm precision potentiometer;
• 02(89): directional switches (forward/reverse or left/right);
• HD11: grip top without pushbutton;
• M6: mounting dimension: 76x76mm, central hole: 92mm.

RunnTech 2 Axis, 4 Directions Joystick to Control Electric Motors for Melting Furnace Tilting

Product configuration: RT100-T-2-V1(10K)-02(89)-HD4-M1

• RT100: RunnTech 100 series joystick controller;
• T: spring return to center operation;
• 2: dual axis, plus (+) directional operation;
• V1: input: 24Vdc, output: -10V…0V…+10Vdc;
• 02(89): 2 directional contacts in each axis;
• HD4: grip top without momentary pushbutton;
• M1: mounting dimension: 56x56mm, central hole: 63mm.
