RunnTech One Axis 4 to 20mA Analog Output Joystick for Solenoid Actuator Control

Product configuration: RT100-M-1-I1(10K)-02(89)-HD2-M1

• RT100: RunnTech 100 series industrial joystick;
• M: mechanical frictional hold operation;
• 1: single axis, 2 directions movement;
• I1: input DC 24V/12V, output: 4mA…12mA…20mA;
• 10K: 10K Ohm conductive-plastic potentiometer;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD2: round ball shape joystick grip;
• M1: mounting dimension 85x85mm, central hole: 63mm.

RunnTech 2 Axis Mechanical Lock Joystick +/-10V Proportional Output for VFD Control

Product configuration: RT100-MS-2-V1(10K)-03(589)-HD5-M1

• RT100: RunnTech RT100 series industrial joystick;
• MS: mechanical friction hold & Lock-in at centre (zero) position;
• 2: dual axis 4 directions;
• V1: input: 24VDC, output: -10VDC…0…+10VDC;
• 03: 3 normally open contact in each direction;
• 589: contact closed position @-32°~-3°, -3°~+3° or +3°~32°;
• HD5: grip with pull to release;
• M1: mounting dimension: 56x56mm, central hole: 63mm.

RunnTech Dual-axis 3 Steps Self-centering Joystick Controller with 10K Potentiometer

Product configuration: RT300-T-3-L-3(1)-P1(10K)-HD3-M5

• RT300: RunnTech RT300 series crane joystick (master controller);
• T: self-centering when released the grip;
• 3: 2 axis, full direction movement;
• L: switch assembled horizontal;
• 3(1): 3 steps each direction, (1): contact arrangement;
• P1: simple 2 directions proportional output;
• HD3: RunnTech joystick handle type;
• M5: mounting dimension: 85x85mm, central hole: 78mm.

RunnTech Multi-axis Joystick Master Contoller with 10K ohm Precision Potentiometer

Product configuration: RT300-TS-3-I-P1(10K)-4(1)-HD39-M5

• RT300: RunnTech RT300 series hoist joystick (master controller);
• TS: spring return to center and center self-lock;
• 3: 2 axis, free movement;
• I: switch assembled vertical;
• P1: simple 2 directions proportional output;
• 10K:10K ohm precision potentiometer;
• 4(1): 4 steps each direction, (3): contacts arrangement;
• M5: mounting dimension: 85x85mm, central hole: 78mm.

RunnTech Single-axis Self-centering Joystick +/-10V Analog Output for Winch Control

Product configuration: RT200-TS-V1(10K)-02(89)-HD5-M1

• RT200: RunnTech 200 series single-axis joystick;
• TS: self-centering with zero interlock (pull to release);
• V1: 24VDC input, -10V…0…+10V proportional output;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD5: joystick grip with zero interlock;
• M1: mounting dimension: 56x56mm, central hole: 63mm;

2018 Chinese Lunar New Year (Spring Festival) Holiday Notice

Please be informed that RunnTech will temporarily break for 2018 Chinese Lunar New Year (Spring Festival) holidays from 13^th February to 22^nd
February. All our staffs will resume to normal operation from 23^rd October.

RunnTech 3 Axis Hall Effect Fingertip Joystick with 1 Pushbutton for Ratiometric Output

Product configuration: RT600-T-3-03-HV2-HD12-BT1

• RT600: RunnTech RT600 series hall miniature joystick controller;
• T: mechanical self-return to center;
• 3: 3 axis control;
• 03: Y and X axis full direction, free movement;
• HV2: input: 5V, output: 0.5V…2.5V…4.5V;
• HD12: RunnTech joystick grip handle model;
• BT1: one momentary pushbutton.

RunnTech 3-axis Mechanical Hold Joystick (3rd axis is Hall Effect Thumbwheel Controller)

Product configuration: RT02-M-3-V1(10K)-02(89)-HD10b8-BT2③②R-W100L-HV1-M6

• RT02: RunnTech 02 series joystick controller;
• M: friction hold position operation;
• 3: dual axis free movement;
• V1: input: DC 24V, output: -10V…0…+10V;
• 10K: potentiometer resistor is 10K;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD10b8: grip with 2 pushbuttons, 1 deadman trigger and 1 thumbwheel;
• W100L-HV1: hall effect thumbwheel, output: 0-2.5-5V;
• M6: mounting dimension: 76x76mm, central hole: 92mm.

RunnTech 1 Axis Friction Hold +/-10V Analog Output Joystick for Proportional Control

Product configuration: RT100-MS-1-V1(10K)-02(89)-HD5-M1

• RT100: RunnTech RT100 series industrial joystick;
• MS: mechanical friction hold & Lock-in at centre (zero) position;
• 1: single axis 2 directions movement;
• V1: input: DC 24V, output: -10V…0…+10V;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD5: grip with mechanical lock-in at 0 position (pull to release);
• M1: mounting dimension: 56x56mm, central hole: 63mm.

RunnTech 2-axis Spring Return Joystick 10V Analog Output with Mechanical Center Lock

Product configuration: RT02-TS-2-V2(10K)-02(89)-HD50-M6

• RT02: RunnTech 02 series joystick controller;
• TS: self-centering and center-lock operation;
• 2: dual axis control;
• V2: input: DC 24V, output: +10V…0…+10V;
• 10K: potentiometer resistor is 10K;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD50: grip with pull to release (mechanical lock-in at 0 position);
• M6: mounting dimension: 76x76mm, central hole: 92mm.
