RunnTech 2-axis Self-centering Joystick 10V Proportional Output with Directional Contact

Product configuration: RT02-T-3-V2(10K)-03(589)-HD11-M6

• RT02: RunnTech 02 series multi-axis joystick;
• T: self-centering operation;
• 3: dual axis free movement;
• V2: voltage output +10V…0V…+10V with 24VDC input;
• 10K: 10K linear conductive plastic track potentiometer per axis;
• 03: 3 normally open contacts in each axis;
• (589): contacts @ -32° to -3°, -3° to +3° or +3° to +32°;
• HD11: grip model;
• M6: mounting dimension: 76x76mm, central hole: 92mm.

RunnTech Dual-axis Self-centering Joystick Proportional Output for VFD Crane System

Product configuration: RT100-T-2-P1(10K)-03(589)-HD1-BT1R-M1

• RT100: RunnTech 100 series joystick controller;
• T: mechanical spring return to center (self-centering);
• 2: dual axis cross movement;
• P1: simple 2 directions proportional output;
• 10K: 10K ohm precision potentiometer;
• 03: 3 normally open contacts in each axis;
• 589: contacts @ -32° to -3°, -3° to 3° or +3° to +32°;
• HD1-BT1R: grip with 1 momentary push button;
• M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech 3 Axis Multi-functional Joystick Controller with Cobra Head Shaped Knob

After our technical team’s efforts, we are proud to announce the successful development of RT90 series joystick controller for multi-functional control & with cobra head shaped knob (RunnTech part number: RT90JAM-4U-46R4GP).

RunnTech 3 Axis Self-centering Hall Effect Joystick with 4mA to 20mA Proportional Output

Product configuration: RT100-T-3-I1(H)-02(89)-HD10b10-W100H-I1(H)-M7

• RT100: RunnTech 100 series multi-axis industrial joystick;
• T: self-returns to center when handle is released;
• 3: dual axis 360° omni-directional movement;
• I1(H): input DC 24V, output: 4mA…12mA…20mA (hall sensor);
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD10b10: joystick grip with 1 deadman trigger;
• W100H: proportional thumbwheel (Z axis);
• I1(H): input DC 24V, output: 4mA~12mA~20mA (hall sensor);
• M7: mounting dimension 85x85mm, central hole: 80x80mm;

RunnTech Single-axis +/-10V Analog Output Joystick for Proportional Directional Valves

Product configuration: RT100-T-1-V1(10K)-02(89)-HD8-M1

• RT100: RunnTech 100 series industrial joystick lever;
• T: joystick returns to center when grip is released (self-centering);
• 1: single axis movement;
• V1: input DC 24V, output: -10V…0V…+10V;
• 10K: 10K Ohm conductive-plastic potentiometer;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD8: RunnTech HD8 grip;
• M1: mounting dimension: 56x56mm, central hole: 63mm;

RunnTech Multi-axis Heavy Duty Omni-directional Movement Proportional Joystick

Product configuration: RT100-T-3-I2(10K)-03(589)-HD2-M1

• RT100: RunnTech 100 series joystick controller;
• T: mechanical spring return to handle centering;
• 3: dual axis 360° omni-directional movement;
• I2: input: 24VVDC, proportional output: 20mA…4mA…20mA;
• 10K: 10K ohm precision potentiometer;
• 03: 3 normally open contacts in each axis;
• (5): contacts @ -3° to +3° (center detect micro-switch);
• (8): contacts @ +3° to +32° (directional micro-switches);
• (9): contacts @ -3° to -32° (directional micro-switches);
• HD2: RunnTech joystick HD2 grip with round knob;
• M1: mounting dimension 56x56mm, central hole: 63mm;

RunnTech Single-axis Analog Voltage Output Electric Scissor Lift & Platform Lifts Joystick

Product configuration: RT100-T-1-V5(10K)-03(589)-HD15-BT1-QTOT-M1

• RT100: RunnTech 100 series industrial joystick controller;
• T: spring return to central operation;
• 1: single axis movement (default: Y axis);
• V5: input: DC24V, output: 0…+10V;
• 10K: 10K ohm precision potentiometer;
• 03: 3 normally open contacts in each axis;
• (5): contacts @ -3° to +3° (center detect micro-switch);
• (8): contacts @ +3° to +32° (directional micro-switches);
• (9): contacts @ -3° to -32° (directional micro-switches);
• HD15: HD15 grip handle with deadman trigger and rocker switch;
• M1: mounting dimension 56x56mm, central hole: 63mm;

RunnTech Single-axis Proportional Joystick for Steel Mill & Offshore Drilling Equipment

Product configuration: RT100-M-1-V5(10K)-02(89)-HD4-BT1R-M1

• RT100: RunnTech 100 series industry joystick controller;
• M: frictional movement to both direction from center;
• 1: single axis movement control;
• V5: input: DC24V, output: 0…+10V;
• 10K: 10K ohm precision potentiometer;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD4-BT1R: HD4 grip top with 1 red momentary pushbutton;
• M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech Multi-axis Proportional Amperage Output Crane Hoisting Equipment Joystick

Product configuration: RT02-T-3-I2(10K)-03(589)-HD9-BT2②R③G-M6

• RT02: RunnTech 02 series multi-axis joystick;
• T: self-centering operation;
• 3: dual axis free movement;
• I2: amperage output 20mA…4mA…20mA with 24VDC input;
• 10K: 10K linear conductive plastic track potentiometer per axis;
• 03: 3 normally open contacts in each axis;
• (589): contacts @ -32° to -3°, -3° to +3° or +3° to +32°;
• HD9-BT2: grip with 2 momentary buttons;
• M6: mounting dimension: 76x76mm, central hole: 92mm.

RunnTech 3-Axis Hall Sensor Self-return 3D Coordinate Measuring Machine Joystick

Product configuration: RT600-T-3-03-HV4-HD12-BT2-M11

• RT600: RunnTech RT600 series contactless hall effect joystick;
• T: self-centering (automatically return to center);
• 3: 3 axis (XYZ) control;
• 03: 3 axis full direction, free movement;
• HV4: input: DC 5V, output: DC 1.25V…2.5V…3.75V;
• HD12: RunnTech joystick grip model;
• BT2: grip top with 2 momentary pushbuttons;
• M11: mounting dimension: 36x36mm, centeral hole: 38mm;
