RunnTech Spring Return to Center Joy Stick with Center Dead Band 10K Potentiometer

Product configuration: RT100-T-1-V5(10K)-02(89)-HD3-M1

• RT100: RunnTech 100 series joystick controller;
• T: spring return to center self-centering;
• 1: single axis (forward and backward) movement;
• V5: input DC 24V, output: 0…10V;
• 10K: 10 Ohm conductive-plastic potentiometer (with “dead band” at center);
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD3: joystick grip model;
• M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech Hall Effect Sensor Joystick for Precision Multi-axes Finger-positioning Control

Product configuration: RT600-T-3-03-HV2-HD12

• RT600: RunnTech RT600 series hall miniature joystick controller;
• T: self-resetting operation;
• 3: 360° free movement;
• 03: 3 axes (X,Y,Z axes);
• HV2: input: 5V, output: 0.5V…2.5V…4.5V;
• HD12: RunnTech joystick grip handle model;

RunnTech 1 Axes Friction Hold Joystick without Neutral Zone in Center of Potentiometer

Product configuration: RT100-M-1-P2(10K)-02(12)-HD2-M1

• M: friction hold position;
• 1: single axis (default: Y axis);
• P2: simple single side output (no dead band at the centre);
• 10K: 10K ohm precision potentiometer;
• 02: 2 directional contacts;
• 12: contact closed position;
• HD2: round ball shape joystick grip;
• M1: mounting dimension;

RunnTech 360° Movement Joystick Lever with Hall Sensor for Hydraulic Valve Bank

Product configuration: RT100-T-3-HV1-02(89)-HD10b2-BT2-③R②G-M7

• RT100: RunnTech 100 series joystick controller;
• T: self-centering movement operation;;
• 3: dual axis, 360° direction movement;
• HV1: input: DC5V, output: 0…2.5…5V;
• HD10b: joystick grip handle with deadman trigger;
• BT2-③R②G: 2 momentary pushbutton;
• M7: mounting dimension 85x85mm, central hole: 80x80mm;

RunnTech Dual-axis 4-20mA Output Joystick Controller with Hall Sensor Thumbwheel

Product configuration: RT100-M-1-I1(10K)-HD10b8-(W100L-HV1)-BT2-②③R-M7

• RT100: RunnTech 100 series joystick control lever;
• M: friction brake operation;
• 1: single axis movement;
• I1: input: DC24V/12V, output: 4mA…12mA…20mA;
• 10K: 10K ohm precision potentiometer;
• HD10b: joystick grip handle with deadman trigger;
• W100L-HV1: thumbwheel with 0~2.5~5V output;
• M7: mounting dimension 85x85mm, central hole: 80x80mm;

RunnTech Single-axis Frictional Movement with Latch for Zero Interlock Joystick Lever

Product configuration: RT200-MS-1-V5(10K)-02(12)-HD5-M1

• RT200: RunnTech 200 series single-axis joystick;
• MS: frictional movement with zero interlock (push to release);
• V5: 24VDC input, 0…+10V analog output;
• 02: 2 contacts;
• 12: contact closed position;
• HD5: joystick grip with zero interlock;
• M1: mounting dimension: 56x56mm, central hole: 63mm;

RunnTech 360° Movement Joystick with +/-10V Output for Lifting & Moving Equipment

Product configuration: RT02-T-3-V1(20K)-02(89)-HD10b6-BT6②③④⑦G④⑤R-M6

• RT02: RunnTech RT02 series joystick controller;
• T: spring return to center self-centering;
• 3: dual axis, 360° free movement;
• V1:input: DC 24V (or 12V), output: -10V…0…+10V;
• 01: 1 directional contacts in each axis;
• 89: contact position;
• HD10b6: grip with deadman trigger and 6 push buttons;
• M6: mounting dimension: 76x76mm, central hole: 92mm.

RunnTech Self Centering 2 Steps 360° Movement for Hoist and Crane Joystick Controller

Product configuration: RT300-T-3-L-2(1)-HD39-M5 (360°)

• RT300: RunnTech RT300 series crane joystick (master controller);
• T: self-centering movement operation;
• 3: dual axis, 360° free movement;
• L:switch assembled horizontal;
• 2(1): 2 steps each direction, (1): contact arrangement;
• HD39: grip with latch (pull to release);
• M5: mounting dimension: 85x85mm, central hole: 78mm.

RunnTech 2-axis 4-20mA Current Output 360° Control Joystick with 6 Momentary Button

Product configuration: RT100-T-3-I2(10K)-02(89)-HD10b6-BT6②③G④⑤Y⑥⑦R-M7

• RT100: RunnTech 100 series joystick control lever;
• T: spring return to central operation;
• 3: dual axis, cross direction movement control;
• I2: input: DC24V, output: 4…20mA;
• 10K: 10K ohm precision potentiometer;
• HD10b: RunnTech joystick grip handle with deadman trigger;
• M7: mounting dimension 85x85mm, central hole: 80x80mm;

RunnTech Single-axis Friction Clutch Joystick Controller for Railway Engineering Vehicles

Product configuration: RT200-MS-1-P1(10K)-03(589)-T-M1

• RT200: RunnTech 200 series joystick controller;
• MS: friction hold with self lock at center;
• P1: simple 2 directions output;
• 10K: 10K ohm precision potentiometer;
• 03(589): 3 switches signal;
• T: T shape joystick grip with push to release;
• M1: mounting dimension: 56x56mm, central hole: 63mm;
