RunnTech Rugged Multi-Axis Tunnel Train Joystick with Trigger and Resistive Potentiometer

News & Events
Product configuration: RT01-T-2-V2(10K)-02(89)-HD10b2-BT2③G②R-M4
  • RT01: RunnTech 01 series rugged industrial joystick;
  • T: mechanical spring return to center;
  • 2: dual axis cross direction movement;
  • V2: input: DC 24V, output: +10V~0~+10V (proportional);
  • 10K: 10K ohm precision potentiometer;
  • 02: 2 normally open contacts in each axis;
  • 89: contacts @ -32° to -3° or +3° to +32°;
  • HD10b2: grip with 1 momentary trigger switch & 2 push button;
  • M4: mounting dimension 64x64mm, central hole: 83mm.

RunnTech Rugged Multi-Axis Tunnel Train Joystick with Trigger and Resistive Potentiometer

RunnTech Single-axis Friction Hold 4-20mA Proportional Output Joystick for Motor Control

News & Events
Product configuration: RT200-MS-I2(10K)-02(89)-HD6-M1
  • RT200: RunnTech 200 series single axis joystick;
  • MS: friction clutch (holds position) and lock-in center;
  • I2: input DC24V, output: 20mA~4mA~20mA;
  • 10K: 10K ohm precision potentiometer;
  • 02: 2 normally open contacts;
  • 89: contacts @ -32° to -3° or +3° to +32°;
  • HD6: joystick grip with zero interlock (press to release joystick);
  • M1: mounting dimension: 56x56mm, central hole: 63mm;

RunnTech Single-axis Friction Hold 4 to 20mA Proportional Output Joystick for Motor Control

RunnTech Single Axis Joysticks with 2 Normally Open Contacts Non Spring Return to Center

News & Events
Product configuration: RT200-MS-P1(10K)-02(89)-HD6-M1
  • RT200: RunnTech 200 series joystick controller;
  • MS: friction hold with center-lock;
  • P1: simple 2 directions output (with center tap);
  • 10K: 10K ohm precision potentiometer;
  • 02: 2 normally open contacts;
  • 89: contacts @ -32° to -3° or +3° to +32°;
  • HD6: RunnTech joystick grip, top with center-lock button;
  • M1: mounting dimension: 56x56mm, central hole: 63mm;

RunnTech Single Axis Joysticks with 2 Normally Open Contacts Non Spring Return to Center

RunnTech Single-axis Voltage Output Joystick with Potentiometer for Proportional Control

News & Events
Product configuration: RT200-T-V2(10K)-02(89)-HD7-BT1R-M1
  • RT200: RunnTech 200 series single axis joystick;
  • T: self-centering movement operation;
  • V2: input DC 24V, output: +10V~0~+10V (proportional);
  • 10K: 2x5K Ohm conductive-plastic potentiometer;
  • 02: 2 normally open contacts in each axis;
  • (89): contacts @ -32° to -3° (backward) or +3° to +32° (forward);
  • HD7-BT1R: grip top with 1 momentary pushbutton;
  • M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech Single-axis Self Centering 4-20mA Joystick with 10K (2x5K) Potentiometer for Proportional Control

RunnTech 3 Axis Compact Precision Contactless Robotic-teach Joystick with 2 Pushbutton

News & Events
Product configuration: RT600-T-3-03-HV1-HD12-BT2-M11
  • RT600: RunnTech RT600 Hall effect robotic-teach joystick controllers;
  • T: self-centering to neutral position;
  • 3: XYZ axis (3 axis) control;
  • 03: XYZ axis full direction, free movement;
  • HV1: input: DC 5V, output: 0V to 2.5V (center) to 5V DC (proportional);
  • HD12-BT2: RunnTech joystick grip with 2 momentary pushbuttons;
  • M11: mounting dimension: 36x36mm, centeral hole: 38mm;

RunnTech 3 Axis Compact Precision Contactless Robotic-teach Joystick Controller with Pushbutton Switch

RunnTech 1 Axis Potentiometer Joystick & Person Present Switch to Control Solenoid

News & Events
Product configuration: RT100-T-1-V1(10k)-02(89)-HD10b2-BT2②G③R-M7
  • RT100: RunnTech 100 series industry joystick controller;
  • T: mechanical spring return to center;
  • 1: single axis operation (default: Y axis);
  • V1: input: DC24V, output: -10V to 0V (center) to +10V analog output;
  • 10K: 10K Ohm conductive-plastic potentiometer with solid center tap;
  • 02: 2 normally open contacts in each axis;
  • 89: contacts @ -32° to -3° or +3° to +32°;
  • HD10b2: HD10 grip with person present swtich;
  • BT2②G③R: 2 momentary push buttons;
  • M7: mounting dimension: 85x85mm, central hole: 80x80mm;

RunnTech Single-axis Joystick with 2x5K Ohm Potentiometer & Person Present Switch to Control Solenoid Coils
