RunnTech RT300 Friction Clutch & Brakes Joy Stick Lever for Flotation Machine & Crusher

Product configuration: RT300-M-I-1-2(2)-HD2-M5

• RT300: RunnTech RT300 series crane joystick (master controller);
• M: frictional clutch operation;
• 1: single axis, Y direction movement;
• I:switch assembled vertically;
• 2(2): Y axis 2 steps each direction, (2): contact arrangement;
• HD2: round ball shape joystick grip;
• M5: mounting dimension: 85x85mm, central hole: 78mm.

RunnTech RT300 Self Centering 2 Steps Belt Conveyor & Cone Crusher Joystick Controller

Product configuration: RT300-T-I-3-2(1)-HD2-M5

• RT300: RunnTech RT300 series crane joystick (master controller);
• T: self-centering movement operation;
• 3: 2 axis, full direction free movement;
• I:switch assembled vertically;
• 2(1): 2 steps each direction, (1): closed position;
• HD2: round ball shape joystick grip;
• M5: mounting dimension: 85x85mm, central hole: 78mm.

RunnTech has been relocated to new workshop

We are pleased to inform you that with effect from 16 June 2017, our company has been relocated to new factory workshop as follows address:

No. 045 Jianzhong Road, Lijia Town, Changzhou, Jiangsu 213165 China

We will strive for providing the excellent service in appreciation of your support.

RunnTech Heavy Duty Dual Axis Joystick -5V & +5V Analog Output for Steel Mills Conveyor

Product configuration: RT100-T-2-V3(10K)-02(89)-HD8-M1

• RT100: RunnTech 100 series industry joystick controller;
• T: spring return to center when release operation;
• 2: dual axis, cross direction movement operation;
• V3: input: DC24V, output: -5V~0~+5V;
• 10K: 10K ohm precision potentiometer;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD8: grip model;
• M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech 200 Series Dual 5V Output Friction Hold Joystick Control Lever Drilling Rig

Product configuration: RT200-M-1-V4(10K)-02(89)-HD7-M1

• RT200: RunnTech 200 series joystick controller;
• M: friction clutch operation (default: Y axis);
• V4: 24VDC input, +5V…0…+5V DC output;
• 02: 2 closed positions;
• 89: closed at 1: 0~3°, 2: 3° to 60°;
• HD7: RunnTech joystick grip;
• M1: mounting dimension: 56x56mm, central hole: 63mm;

RunnTech Dual Axis -5V & +5V Analog Output with Full Free Range Motion Joystick Lever

Product configuration: RT100-T-3-V3(10K)-02(89)-HD8-M1

• RT100: RunnTech RT100 series joystick controller;
• T: spring return device (automatically return to center);
• 3: Y & X axis with full free range motion;
• V3: input: DC24V, output: -5V…0…+5V;
• 10K: 10K ohm precision potentiometer;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD8: RunnTech joystick grip;
• M1: mounting dimension: 56x56mm, central hole: 63mm.

RunnTech Dual Axis 4 to 20mA Y & X Axis with Full Free Range Motion Joystick Controller

Product configuration: RT100-T-3-I2(5K)-HD7-BT1R-M1

• RT100: RunnTech RT100 series joystick controller;
• T: spring return device (automatically return to center);
• 3: Y & X axis with full free range motion;
• I2: I2: input DC 24V, output: 20mA…4mA…20mA;
• HD7-BT1R: RunnTech joystick grip with 1 push button;
• M1: mounting dimension: 56x56mm, central hole: 63mm.

RunnTech Multi-axis Spring Return to Center with Hall Sensor & Deadman Trigger Joystick

Product configuration: RT100-T-3-HV1-03(589)-HD10b-M7

• RT100: RunnTech RT100 series joystick controller;
• T: spring return to center self-centering;
• 3: dual axis, free movement;
• HV1: Hall sensor input: DC 5V, output: 0…2.5…5V;
• 02: 2 directional contacts;
• 89: closed position;
• HD10b: RunnTech joystick grip with deadman trigger;
• M7: mounting dimension: 85x85mm, central hole: 80x80mm.

RunnTech RT100 Friction Hold Joystick Controller with Deadman Trigger & Rocker Switch

Product configuration: RT100-M-1-Y-V2(1K)-02(89)-HD15-BT1-QTOT-M1

• RT100: RunnTech RT100 series joystick controller;
• M: frictional hold operation;
• 1: single axis movement (Y axis);
• V2: input: DC 24V, output: dual 10VDC;
• 1K: 1K ohm precision potentiometer;
• 02: 2 normally open contacts in each axis;
• 89: contacts @ -32° to -3° or +3° to +32°;
• HD15-BT1R: RunnTech joystick grip with deadman trigger;
• M1: mounting dimension: 56x56mm, central hole: 63mm.

RunnTech 3-Axis Hall Effect Compact Analog to Digital Output Joystick with RS-232 Port

Product configuration: RT600-T-3-03-HV1-HD12-BT2-RS232

• RT600: RunnTech RT600 series hall miniature joystick controller;
• T: automatically return to center position;
• 3: 3 axis control;
• 03: Y and X axis, free movement;
• HV1: input: DC 5V, output: DC 0V…2.5V…5V (rail to rail);
• RS232: analog output is converted to digital output with RS232;
• HD12: RunnTech joystick grip model;
• BT2: 2 momentary thumb push buttons;
